CATALOG
Parts List
Part Number
Description
Drawing
A2541T3x-xx
Crimp Terminal
PDF
A2541H00-1XNP
Single Row Housing
PDF
A2541H00-2XNP
Dual Row Housing
PDF
A2541WV0-1XNP
180° Single Row Wafer
PDF
A2541WV0-2XNP
180° Dual Row Wafer
PDF
A2541WR0-1XNP
90° Single Row Wafer
PDF
A2541WR0-2XNP
90° Dual Row Wafer
PDF
A2541
Current Rating: 3A AC, DC
Voltage Rating: 250V AC
Contact Resistance: 20MΩ Max.
Insulation Resistance: 1,000MΩ Min.
Withstanding Voltage: 1,000V AC/minute
SPECIFICATION SHEET
Dual Row DIP Type
Single Row DIP Type
Dual Row SMT Type
Single Row SMT Type
